Single-acting Pump for Pails

PBlll-30/45

Market

Automotive Market

Used for vehicle powertrains and electrical components, construction machines, and marine vessels.
Electronics Market

Used for electrical appliances such as mobile phones and computers.
Public Industrial Material Market

Used for infrastructure, construction, and general machines.

Function

※Membership registration or login is required to view SDS / technical materials.

Features / Technology

Best suited to high-pressure pumping of high-viscosity materials (pump ratio: 30:1 or 45:1).
A design taking the remaining amount into consideration was incorporated. This reduced the remaining amount by 30 to 50% compared with that of the previous products.

Outer dimensions

PBlll-30: W430×D500×H1031.4 to 1458.4 mm, PBlll-45: W430×D500×H1050.4 to 1477.4 mm

Weight

PBlll-30: 120 kg, PBlll-45: 120 kg

Drive Sources

Clean dry air: 0.3 to 0.6 MPa

Suitable Materials

Moisture curing sealants and adhesives of the ThreeBond 1200 series

Suitable packaging

Pail
